Industry related knowledge

We will generally make MARK coordinates, and then through MARK identification to do component library, patch first identify MARK then patch; MARK identification after how to judge the MARK deviation, whether based on the identification results and then locate MARK center coordinates and program MARK coordinates comparison, get the deviation, and then act on the patch coordinates.

In motion, the placement alignment technique aligns:

• CCD mounted on the patch head;
• The loading speed QFP by this method decreased from 0.7 s to 0.3 s;.
• CCD suspension installation;
• conducive to correcting position in SMC/SMD motion.

When a new PCB to be mounted is transmitted to a designated location through a board feeding mechanism, the reference (MARK point) camera mounted on the patch head CCD3 the corresponding area is searched by image recognition algorithm, and its coordinates in the coordinate system are calculated by the system software, and the location data of the corresponding components should be pasted to the main control computer. When the corresponding mounting components are picked up and passed through the component camera, the camera detects the components, obtains their position coordinates after picking up and sends them to the main control computer, compares with the target position, obtains the position and rotation angle that the mounting head should move, and adjusts the position and rotation angle before sticking, so as to achieve the purpose of visual alignment.
